Bakelite handle Manufacturer in China
Dual side handles for pots exist because a 12 L stockpot filled to the rim carries more weight than one wrist should take. A dual side handle set is a matched left and right pair: two phenolic grips on steel brackets, pressed from the same charge and drilled to one hole pattern. Ordered as one part number per pot size, the pair sits at one height and a full pot hangs level between two hands.
What are dual side handles for pots?
Dual side handles for pots are two phenolic grips rated 160–180°C continuous, fixed at matching height on opposite walls so a filled pot is carried with both hands. Each half is short, so a wide body gets two grip points without a long lever arm pulling at the wall. Both halves follow one drawing, so the set is quoted as a pair, not as two loose parts.
Which pots need a matched pair?
A 12 L stockpot and a cast-iron Dutch oven are the two bodies where a pair earns its place, because both are lifted with two hands even before they are filled. Fit follows the pot drawing: bracket height, hole spacing and grip length come off the wall, and both handles are set on the same band so the hands meet the pot level. Wide casserole bodies and deep sauté pans use the same profile when the rim is too broad for a single grip.
How does the pair handle 160–180°C?
Each grip holds 160–180°C continuous, and special modified grades reach 200–220°C when a lidded pot moves from hob to oven. Heat arrives through the steel bracket rather than the air, so both halves are pressed to one thickness and warm at the same rate. Phenolic is a thermoset: once cured it does not soften again in the range a pot wall reaches, so neither side sags toward the rim on a long braise.
Technical specifications
The table carries the 2,000 pcs order terms for a matched pair, from resin grade through to the 20–25 day container lead time.
| Property | Value |
|---|---|
| Material | Phenolic resin, PF2A2 or PF2A4-151J |
| Configuration | Matched left and right grip, one set per pot size |
| Continuous heat | 160–180°C |
| Modified grade heat | 200–220°C |
| Bracket | Steel, drilled to the pot drawing |
| Grip surface | Smooth or textured, identical on both halves |
| Colour | Pigmented in the resin or painted |
| MOQ | 2,000 pcs |
| Lead time | 20–25 days for a full 20GP container quantity |
| Test standard | EN 12983-1:2023 |
Which mounting options keep the pair aligned?
Three fixings are quoted at 2,000 pcs, and each one holds the pair at a single height: a riveted steel bracket, a screw through the bracket into a moulded boss, and a bracket welded to the wall before coating. Hole spacing comes off the drawing for both sides, so a replacement set drops onto the existing drill points.
- Riveted steel bracket, one per side, set at the same height.
- Screw through the bracket into a moulded boss.
- Bracket welded to the pot wall before the coating step.
- Hole spacing copied to both sides from the pot drawing.
- Resin pigmented before pressing for a through colour.
- Sprayed finish after moulding for a two-tone line.
How is a matched pair moulded and checked?
Both halves come off the same cavity on 20+ compression presses running a combined 70,000 pcs/day, and the pair is measured against EN 12983-1:2023 before packing.
- Weigh the PF2A2 or PF2A4-151J charge for each half.
- Preheat the charge and load it into the steel cavity.
- Close the heated press and hold until the section cures.
- Deflash the parting line and dress the grip surface.
- Check bracket height, hole spacing and finish on both halves against the drawing and EN 12983-1:2023.
Frequently asked questions
Four questions come back before most 2,000 pcs pair orders are released.
Do both handles in a pair weigh the same?
Both halves of a 2,000 pcs run come from one cavity and are weighed at the press, so the pair hangs level when lifted.
Can a pair be fitted to a 12 L stockpot?
A 12 L stockpot is matched from its drawing: bracket height, hole spacing and grip length are set before tooling starts. Send a sample pot and the pair is dry-fitted to the wall before a 2,000 pcs run.
What happens if one grip is dropped?
A 2,000 pcs order is pressed as identical halves, so one dropped grip is replaced from stock instead of from a new press run, and it lines up with the bracket already on the pot.
What are the order terms for a pair?
MOQ is 2,000 pcs, and a full 20GP container quantity ships in 20–25 days after the sample pair is approved.
Key takeaways
A pair is ordered at 2,000 pcs and ships in 20–25 days once the sample is approved.
- Matched left and right phenolic grips on steel brackets, rated 160–180°C continuous.
- 200–220°C on modified grades for pots that go from hob to oven.
- Rivet, screw or weld fixing, all quoted at 2,000 pcs with a 20–25 day container lead time.
Orders start at 2,000 pcs, and a full 20GP container quantity runs 20–25 days. We press a sample pair to your pot drawing and release production once that pair is approved. Send the pot diameter, wall thickness and bracket hole spacing to sales@bshouseware.com and we return the sample date.
Related parts: pot side handles, side handles for cookware, cookware side grips, casserole side handles, saucepan side grips, and the full bakelite side handle range.
Request a sample or email sales@bshouseware.com with your pot drawing.
