Glass Lid Supplier - G-Type Tempered Lids, 2,000 pcs

Glass lid/

Glass Lid Supplier – G-Type Tempered Lids

Application:All Types of Frying Pans, Pots, Woks, Saucepans,ceramic cookware,casserole
Glass Material:Tempered Floating Glass
Glass thickness:3.0mm/3.6mm/3.8mm/4.0mm/5mm,ect
Rim Material:Stainless Steel
Lids Size:Φ12/14/16/18/20/22/24/26/28/30/32/34/36/38/40cm
Materials of rim:SS201, SS202, SS304 etc.
Polishing of rim:shiny or Matt
Colour of rim:,Silver, Grey, Golden, Bronze, Red , Original of metal,Multicolored etc. (Customizable)
Colour of Glass:Transparent, Blue, Green, Brown etc.
Quantity of hole for knob:Size and Quantity Can be Customized.
Heat Resistant Range:250 Degree Centigrade
Glass Plate:Standard Dome, High Dome and Flat Version etc.
Logo:Customizable
Package:Paper mat between 2 lids or each lid in a poly-bag,suitable quantity of lids in a carton
MOQ:1000pcs/Size

  • Product Detail

As a glass lid supplier we build the G-type cover: a stepped stainless rim that drops inside the pan edge, in 4.0 mm tempered glass from a 2,000 pcs minimum. The step is what holds the lid in place during a rolling boil, so the rim profile is matched to your pan before the run is released.

What is a G-type tempered glass lid?

The G-type lid pairs a 4.0 mm tempered glass panel with a stainless rim pressed into a G-shaped step. The step sits inside the pan mouth, so the lid centres itself instead of sliding across the rim. Diameter and rim depth are taken from the pan drawing, and one 2,000 pcs run keeps both dimensions fixed.

How is the G rim shaped to seal a pan?

The rim is rolled to a seat that holds the 4.0 mm glass, then stepped outward and down so it rests against the pan wall. That deep step is what creates the seal on a round pan mouth. Because the metal wraps the glass edge, the panel is protected from knocks when the lid is set down between stirs.

Technical specifications

A G-type purchase order carries the 4.0 mm glass, the rim grade and the 2,000 pcs minimum on one sheet.

PropertyValue
Glass4.0 mm heat-treated tempered glass
RimStainless steel, #304 or #201
Rim profileG-shaped step, seated inside the pan mouth
VentSteam release hole through the panel
HandleBakelite knob in phenolic, or metal handle
Heat220°C for the glass and rim
MOQ2,000 pcs
Lead time20–25 days for a full 20GP container quantity
Test standardEN 12983-1:2023

Which materials and thicknesses are used?

Two rim grades are quoted at 2,000 pcs, #304 and #201 stainless, and the glass is 4.0 mm on the standard G-type. The grade is fixed per drawing rather than per order, so a repeat run matches the first lot. A deeper rim is available where the pan wall is thicker than the standard pressing.

What does a supplier order include?

An order at 2,000 pcs covers the lid, the knob and the packing on one quotation, so nothing is added after the run starts. Four items are settled before tooling.

  • Lid diameter in mm, measured across the pan opening.
  • Rim grade, #304 or #201 stainless.
  • Handle type: bakelite knob, metal handle, or no handle.
  • Packing: bulk carton, or a set packed with the pan.

Diameter drives the rest. A 1 mm change in the pan opening moves the rim step, so the opening is measured on a sample pan rather than read from a catalogue size.

How are the lids produced and checked?

Glass is cut and tempered in house, and 20+ presses with 70,000 pcs/day of combined capacity carry the rim and knob work. Inspection follows EN 12983-1:2023.

  1. Cut the panel to the pan diameter and drill the vent hole.
  2. Heat the panel and quench it under controlled air to temper it.
  3. Roll the stainless rim to the G profile and press it onto the panel.
  4. Fit the knob or handle and check the seat for play.
  5. Measure diameter, rim depth and knob torque against the drawing and EN 12983-1:2023.

Frequently asked questions

Four questions come up before most 2,000 pcs G-type orders are released.

Does the vent stop boil-overs?

The single vent hole in the 4.0 mm panel releases pressure before it lifts the lid, which is what keeps a simmer from climbing the pan wall. It also holds the glass clear of fog, so the food stays visible without the cover being raised.

Can the rim be #304 instead of #201?

Both grades are quoted at 2,000 pcs, and the choice is written on the drawing before the rim is rolled. #304 is specified where the lid must hold a bright finish through heavy washing, and the two grades share one rim profile.

Will a bakelite knob fit the same lid?

A bakelite knob is fitted through the centre hole of the same 4.0 mm panel and quoted with the lid at 2,000 pcs. The knob is phenolic, while the 220°C rating of the lid is set by the glass and the stainless rim.

What are the order terms?

MOQ is 2,000 pcs, and a full 20GP container quantity ships in 20–25 days after the sample is approved. A diameter change needs a new rim roll, so sizes are grouped per container.

Key takeaways

Five points define a 2,000 pcs G-type order.

  • 4.0 mm tempered glass in a G-shaped stainless rim that seats inside the pan mouth.
  • Rim in #304 or #201, chosen on the drawing before rolling.
  • Steam vent and a 220°C rating for the glass and rim.
  • 2,000 pcs MOQ with a 20–25 day container lead time.
  • 20+ presses, 70,000 pcs/day, each lot tested to EN 12983-1:2023.

Every G-type order starts at a 2,000 pcs minimum and runs 20–25 days for a full 20GP container quantity once the sample is signed off. Send the pan diameter and rim grade to sales@bshouseware.com and we reply with the tooling date.
